Ultima DICOM Converter

Ultima DICOM Converter

The easy way to Bring

Non-DICOM formats into your PACS



Download datasheet

Ultima DICOM Converter




Ultima DICOM Converter is a powerful and user-friendly software application that enables you to easily convert images, scanned documents, digitized medical films and video captures to DICOM format.




Ultima DICOM Converter is a powerful and user-friendly software application that enables you to easily convert images, scanned documents, digitized medical films and video captures to DICOM format and send them to PACS for inclusion with the patient records.


Interested in this product ?


KEY FEATURES
  • Convert to DICOM from different sources :
    • All kinds of Windows images (JPG, BMP, PNG files)
    • Scanned documents from any TWAIN-compliant scanner
    • DirectShow captures of analog video frames
    • Scanned medical films from VIDAR digitizer
  • Create new Patients / Studies manually
  • Get patient & study information from a DICOM Server (PACS) or a modality worklist using the search tool
  • Reconcile converted images, scans, or digitized films with the PACS
  • Easily configure an unlimited number of DICOM destinations
  • Send images to a default destination automatically
  • Image edition tools
  • Creation of users’ accounts
  • Complete Audit Log of converted and sent images


Interested in this product ?


CONNECTIVITY AND DICOM SERVICES
  • C-ECHO SCU
  • C-FIND SCU
  • C-FIND MWL SCU
  • C-STORE SCU
PC DELL OPTIPLEX 7010 DT (OPTIONAL)
  • Processors Intel® 3rd generation Core™ i3
  • Memory SDRAM 4GB Non-ECC DDR3 1600MHz
  • Microsoft® Windows 7® Professional (32 bits)
  • 3.5” Hard Drives 500GB 7200 RPM SATA
  • Dimensions (H x W x D) Inches/(cm) 14.2 x 4 x 16.1 / (36 x 10.2 x 41)
  • Weight (lbs/ kg) 17.38/7.9
  • Power Supply Unit (PSU): Standard 250W PSU: 50 and 60 Hz
  • Networking: Integrated Intel® 82579LM Ethernet LAN 10/100/1000
  • Black Flat screen E2014H 49,4cm (19.5”), VGA and DVI-D
  • Dell USB Optical Mouse and Keyboard
VIDAR DIAGNOSTIC PRO EDGE (OPTIONAL)
  • Film Sizes
    • Width: 7” to 14” (18 cm to 35.6 cm), 3 inch minimum manual feed
    • Length: 8” to 17” (20 cm to 43 cm , 3 inch minimum manual feed
    • Single film mode: min. length of 3” (7.6 cm), max. length of 51” (129.5 cm) can be accommodated in single film mode only
  • Auto Film Feeder
    • Standard 25-film capacity (mixed sized – no presorting necessary)
    • “Light Box” loading: head-up, normal reading, left justified
  • Scan Rate 400 lines/second
  • Hardware Interface usb 2.0
  • Power Requirements
    • Voltage: 85~264 Vac
    • Frequency: 47~63 Hz
    • Power: 48 Watts
  • With Feeder & Exit Tray: 18” W x 17.5” D x 24.5” H (457mm x 445mm x 622 mm)
VIDAR DIAGNOSTIC PRO ADVANTAGE (OPTIONAL)
VIDAR SIERRA ADVANTAGE (OPTIONNEL)
VIDAR CAD PRO ADVANTAGE (OPTIONAL)


Interested in this product ?
